Pomodoro Timer

blueprint:
  name: AWTRIX Pomodoro Timer
  description: Creates custom app for AWTRIX device with Pomodoro timer
  domain: automation
  author: Lufton
  source_url: https://github.com/lufton/ha-blueprints/blob/main/awtrix_pomodoro_timer.yaml
  input:
    awtrix_device:
      name: AWTRIX Device
      description: Select the AWTRIX device
      selector:
        device:
          integration: mqtt
          manufacturer: Blueforcer
    app_name:
      name: App name
      description: Enter app name or leave as is for default value
      default: Pomodoro
    timer:
      name: Timer
      description: Select timer to be used as pomodoro timer (create helper timer and set default cycle duration, e.g. 25 minutes)
      selector:
        entity:
          filter:
            domain: timer
    counter:
      name: Counter
      description: Select counter to be used as completed pomodoros (create helper counter and set minimum to 0, maximum to 16, initial to 0 and step to 1)
      selector:
        entity:
          filter:
            domain: counter
    short_break:
      name: Short break
      description: Set short break duration (short break is a regular break between pomodoros), e.g. 5 minutes
      default:
        minutes: 5
      selector:
        duration:
    long_break:
      name: Long break
      description: Set short break duration (long break is a break after each pomodoro that is multiple of 4), e.g. 15 minutes
      default:
        minutes: 15
      selector:
        duration:
    reminder:
      name: Reminder
      description: Set reminder duration (reminder will be played if timer is not started or paused), e.g. 5 minutes
      default:
        minutes: 5
      selector:
        duration:
    show_pomodoros:
      name: Show pomodoros
      description: >-
        Check to show red dots around timer that indicates completed pomodoros:

        Blinking dot – current pomodoro

        Short space – short break

        Long space – long break
      default: true
      selector:
        boolean:
    illuminance_threshold:
      name: Illuminance threshold
      description: Set illuminance threshold that is gonna be checked to determine if pomodoro should be reset
      default: 1
      selector:
        number:
          min: 0
          max: 10
          unit_of_measurement: lx
    reset_time:
      name: Reset time
      description: Set time when pomodoros should reset (usually at night time when timer is not in use)
      default:  03:00:00
      selector:
        time:
    start_text:
      name: Start text
      description: Enter text as a hint for user to press a button to start pomodoro
      default: Press
      selector:
        text:
    done_text:
      name: Done text
      description: Enter text as a hint for user when all pomodoros are completed
      default: Done!
      selector:
        text:
    blink_text:
      name: Blink text
      description: Enter interval of text blinking (set 0 to avoid blinking)
      default: 500
      selector:
        number:
          min: 0
          max: 5000
          step: 100
          unit_of_measurement: ms
    pomodoro_icon:
      name: Pomodoro icon
      description: Enter icon number/filename for pomodoro timer
      default:
    break_icon:
      name: Break icon
      description: Enter icon number/filename for break timer
      default:
    start_rtttl:
      name: Start rtttl sound
      description: Enter rtttl sound that will be played when timer is ready to start (enter space to prevent playing any sound)
      default: PomodoroStart:d=4,o=5,b=100:8e,8g,8c6,8e,8c6,8g,8e,8c6
    finish_rtttl:
      name: Finish rtttl sound
      description: Enter rtttl sound that will be played when timer is finished (enter space to prevent playing any sound)
      default: PomodoroFinish:d=4,o=5,b=100:8c,8g,8c6,8g,8c6,8g,8c6,8g,8c6
    reminder_rtttl:
      name: Reminder rtttl sound
      description: Enter rtttl sound that will be played when timer is not active (not started or paused, enter space to prevent playing any sound)
      default: PomodoroReminder:d=4,o=5,b=120:8c,8e,8g,8c6
trigger_variables:
  awtrix_device: !input awtrix_device
  illuminance_threshold: !input illuminance_threshold
  timer: !input timer
  button: "{{ (device_entities(awtrix_device) | select('search', 'button_select') | list)[0] }}"
  illuminance: "{{ (device_entities(awtrix_device) | select('search', 'illuminance') | list)[0] }}"
  current_app: "{{ (device_entities(awtrix_device) | select('search', 'current_app') | list)[0] }}"
variables:
  app_name: !input app_name
  device_topic: "{{ states((device_entities(awtrix_device) | select('search', 'device_topic') | list)[0]) }}"
  app_topic: "{{ device_topic }}/custom/{{ app_name }}"
  notify_topic: "{{ device_topic }}/notify"
  switch_topic: "{{ device_topic }}/switch"
  rtttl_topic: "{{ device_topic }}/rtttl"
  switch_payload:
    name: "{{ app_name }}"
  counter: !input counter
  short_break: !input short_break
  long_break: !input long_break
  reminder: !input reminder
  show_pomodoros: !input show_pomodoros
  reset_time: !input reset_time
  start_text: !input start_text
  done_text: !input done_text
  blink_text: !input blink_text
  pomodoro_icon: !input pomodoro_icon
  break_icon: !input break_icon
  start_rtttl: !input start_rtttl
  finish_rtttl: !input finish_rtttl
  reminder_rtttl: !input reminder_rtttl
trigger:
  - platform: state
    entity_id: !input timer
    to: active
    alias: Timer started
    id: timer_started
  - platform: state
    entity_id: !input timer
    to: paused
    id: timer_paused
    alias: Timer paused
  - platform: state
    entity_id: !input timer
    to: idle
    id: timer_stopped
    alias: Timer stopped
  - alias: Button pressed
    platform: template
    value_template: "{{ is_state(button, 'on') }}"
    id: button_pressed
  - alias: Day ended
    platform: time
    at: !input reset_time
    id: day_ended
    enabled: true
  - alias: Illuminance sensor closed
    platform: template
    value_template: "{{ states(illuminance) | int <= illuminance_threshold }}"
    id: illuminance_sensor_closed
action:
  - choose:
      - conditions:
          - condition: trigger
            id: timer_started
        sequence:
          - service: mqtt.publish
            data:
              topic: "{{ switch_topic }}"
              payload: "{{ switch_payload }}"
          - repeat:
              sequence:
                - service: mqtt.publish
                  data:
                    topic: "{{ app_topic }}"
                    payload: >-
                      {% set it_is_a_break = trigger.from_state.attributes.duration != trigger.to_state.attributes.duration %}
                      {% set duration = as_timedelta(state_attr(timer, 'duration')).total_seconds() %}
                      {% set remaining = (as_datetime(state_attr(timer, 'finishes_at')) - now().replace(microsecond=0)).total_seconds() %}
                      {% set progress = (duration - remaining) / duration %}
                      {% set draw = namespace(items=[]) %}
                      {% for i in range(states(counter) | int + 1) %}
                        {% if not loop.last or (remaining % 2 == 0 and not it_is_a_break) %}
                          {% set draw.items = draw.items + [dict(dp=[12 + (2 if (i % 8) > 3 else 0) + ((i * 2) % 16), 0 if i < 8 else 6, [255 * progress, 0, 0] if loop.last and not it_is_a_break else "#FF0000"])] %}
                        {% endif %}
                      {% endfor %}
                      {{ dict(icon=break_icon if it_is_a_break else pomodoro_icon, text=remaining | timestamp_custom('%M:%S' if remaining % 2 == 0 else '%M %S', False), progress=(progress * 100) | round(0), draw=draw.items if show_pomodoros else []) }}
                - wait_template: "{{ not is_state(timer, 'active') }}"
                  continue_on_timeout: true
                  timeout: 1
              while:
                - condition: template
                  value_template: "{{ is_state(timer, 'active') }}"
      - conditions:
          - condition: trigger
            id: timer_paused
        sequence:
          - service: mqtt.publish
            data:
              topic: "{{ switch_topic }}"
              payload: "{{ switch_payload }}"
          - repeat:
              sequence:
                - wait_template: "{{ not is_state(timer, 'paused') }}"
                  continue_on_timeout: true
                  timeout: "{{ reminder.get('hours', 0) * 3600 + reminder.get('minutes', 0) * 60 + reminder.get('seconds', 0) }}"
                - if:
                    - condition: template
                      value_template: "{{ not wait.completed }}"
                  then:
                    - service: mqtt.publish
                      data:
                        topic: "{{ rtttl_topic }}"
                        payload: "{{ reminder_rtttl }}"
              until:
                - condition: template
                  value_template: "{{ not is_state(timer, 'paused') }}"
      - conditions:
          - condition: trigger
            id: timer_stopped
          - condition: template
            value_template: "{{ (states(illuminance) | int > illuminance_threshold or not is_state(current_app, app_name)) and now().replace(microsecond=0) != today_at(reset_time) }}"
        sequence:
          - service: mqtt.publish
            data:
              topic: "{{ switch_topic }}"
              payload: "{{ switch_payload }}"
          - if:
              - condition: template
                value_template: "{{ trigger.from_state.attributes.duration == trigger.to_state.attributes.duration }}"
            then:
              - service: mqtt.publish
                data:
                  topic: "{{ rtttl_topic }}"
                  payload: "{{ finish_rtttl }}"
              - service: counter.increment
                target:
                  entity_id: "{{ counter }}"
              - if:
                  - condition: template
                    value_template: "{{ is_state(counter, state_attr(counter, 'maximum') | string) }}"
                then:
                  - service: counter.reset
                    target:
                      entity_id: "{{ counter }}"
                  - service: mqtt.publish
                    data:
                      topic: "{{ app_topic }}"
                      payload: "{{ dict(icon=pomodoro_icon, text=done_text, blinkText=blink_text) }}"
                  - delay:
                      seconds: 5
                  - service: mqtt.publish
                    data:
                      topic: "{{ app_topic }}"
                      payload: "{{ dict(icon=pomodoro_icon, text=start_text, blinkText=blink_text) }}"
                else:
                  - service: timer.start
                    data:
                      duration: >-
                        {% if states(counter) | int % 4 == 0 %}{{ long_break }}
                        {% else %}{{ short_break }}
                        {% endif %}
                    target:
                      entity_id: "{{ timer }}"
            else:
              - service: mqtt.publish
                data:
                  topic: "{{ app_topic }}"
                  payload: "{{ dict(icon=pomodoro_icon, text=start_text, blinkText=blink_text) }}"
              - repeat:
                  sequence:
                    - wait_template: "{{ is_state(timer, 'active') }}"
                      continue_on_timeout: true
                      timeout: "{{ reminder.get('hours', 0) * 3600 + reminder.get('minutes', 0) * 60 + reminder.get('seconds', 0) }}"
                    - if:
                        - condition: template
                          value_template: "{{ not wait.completed }}"
                      then:
                        - service: mqtt.publish
                          data:
                            topic: "{{ rtttl_topic }}"
                            payload: "{{ reminder_rtttl }}"
                  until:
                    - condition: template
                      value_template: "{{ is_state(timer, 'active') }}"
      - conditions:
          - condition: trigger
            id: button_pressed
          - condition: template
            value_template: "{{ is_state(current_app, app_name) }}"
        sequence:
          - wait_template: "{{ is_state(button, 'off') }}"
          - condition: template
            value_template: >-
              {% set duration = as_timedelta(state_attr(timer, 'duration')).total_seconds() %}
              {% set short_break_duration = 3600 * short_break.get('hours', 0) + 60 * short_break.get('minutes', 0) + short_break.get('seconds', 0) %}
              {% set long_break_duration = 3600 * long_break.get('hours', 0) + 60 * long_break.get('minutes', 0) + long_break.get('seconds', 0) %}
              {{ (duration != short_break_duration) and (duration != long_break_duration) }}
          - if:
              - condition: template
                value_template: "{{ is_state(timer, 'active') }}"
            then:
              - service: timer.pause
                target:
                  entity_id: "{{ timer }}"
            else:
              - service: timer.start
                target:
                  entity_id: "{{ timer }}"
      - conditions:
          - condition: template
            value_template: "{{ trigger.id == 'day_ended' or (trigger.id == 'illuminance_sensor_closed' and is_state(current_app, app_name)) }}"
        sequence:
          - service: counter.reset
            target:
              entity_id: "{{ counter }}"
          - service: timer.cancel
            target:
              entity_id: "{{ timer }}"
          - service: mqtt.publish
            data:
              topic: "{{ app_topic }}"
              payload: "{{ dict(icon=pomodoro_icon, text=start_text, blinkText=blink_text) }}"
mode: parallel
max: 10
