Countdown Timer
A Countdown Timer for Awtrix Light
| System | Home Assistant |
|---|---|
| Firmware | AWTRIX 3 |
| Topic | Smarthome |
| Built by | Hank_the_Tank |
| File | wq2NANplO7KV.yaml · 3.3 KB |
| Icons | — |
| Published | 9 Nov 2023 · updated 10 Nov 2023 |
| Downloads | 29 |
Things you have to do:
Create a Timer helper in HA (Settings> Devices&Services> Helpers> +Create Helper> Timer) give it a name "awtrix timer" and set your desired duration.
Download The Lametric icon ID 42893 to your Awtrix.
Copy short.txt file to your /MELODIES folder of your Awtrix. Content of short.txt file "two short:d=4,o=5,b=100:16e6,16e6" (without the quotes)
Change topic: awtrix_xxxxxx
Special Thanks to TheFes for the Payload
wq2NANplO7KV.yaml
alias: ⏳AWTRIX Timer
description: ""
trigger:
- platform: state
entity_id:
- timer.awtrix_timer
to: active
id: start
- platform: state
entity_id:
- timer.awtrix_timer
to: idle
id: stop
condition: []
action:
- choose:
- conditions:
- condition: trigger
id:
- start
sequence:
- parallel:
- repeat:
sequence:
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/custom/timer
payload: >
{% set duration =
as_timedelta(state_attr('timer.awtrix_timer',
'duration')).total_seconds() %} {% set remaining =
as_datetime(state_attr(trigger.entity_id,
'finishes_at')) - now().replace(microsecond=0) %} {%
set passed = duration - remaining.total_seconds() %}
{% set progress = ((passed/duration) * 100) | round(0)
| int %} {{
dict(
icon = '42893',
text = remaining | string,
progress = progress,
progressC = '#ff0000',
progressBC = '#000000'
)
}}
- delay:
hours: 0
minutes: 0
seconds: 1
milliseconds: 0
while:
- condition: state
entity_id: timer.awtrix_timer
state: active
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/settings
payload: "{\"ATRANS\": false}"
- repeat:
count: 1
sequence:
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/switch
payload: "{\"name\":\"timer\"}"
- conditions:
- condition: trigger
id:
- stop
sequence:
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/sound
payload: "{\"sound\":\"short\"}"
- delay:
hours: 0
minutes: 0
seconds: 1
milliseconds: 0
- parallel:
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/custom/timer
- service: mqtt.publish
data:
qos: 0
retain: false
topic: awtrix_a8ba90/settings
payload: "{\"ATRANS\": true}"
mode: restartMore flows for Home Assistant or Smarthome
