Diabetes
Diabetes Management
| System | Home Assistant |
|---|---|
| Firmware | AWTRIX 3 |
| Topic | Miscellaneous |
| Built by | Sebastian |
| File | wq2NANZRA7KV.yaml · 9.6 KB |
| Icons | 8 |
| Published | 3 Nov 2025 · updated 3 Nov 2025 |
| Downloads | 43 |
Diabetes Management Glucose Data Transfer
wq2NANZRA7KV.yaml
[
{
"id": "7057b52ef757d606",
"type": "tab",
"label": "Awtrix-Nightscout-Pixel",
"disabled": false,
"info": "",
"env": []
},
{
"id": "e7101a5caeb46470",
"type": "inject",
"z": "7057b52ef757d606",
"name": "Start",
"props": [
{
"p": "payload"
},
{
"p": "topic",
"vt": "str"
}
],
"repeat": "5",
"crontab": "",
"once": false,
"onceDelay": 0.1,
"topic": "",
"payload": "",
"payloadType": "date",
"x": 90,
"y": 180,
"wires": [
[
"1ac6b90937457bf7"
]
]
},
{
"id": "25b695a46aa59b69",
"type": "change",
"z": "7057b52ef757d606",
"name": "Command: Data query",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "curl -H \"Content-Type: application/json\" -H \"Authorization: Bearer TOKEN\" -X GET https://NIGHTSCOUT_URL:PORT/api/v1/entries.json?count=1",
"tot": "str"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 760,
"y": 180,
"wires": [
[
"1e1f42891a8b5b97"
]
]
},
{
"id": "fd30a342bc5bed2f",
"type": "exec",
"z": "7057b52ef757d606",
"command": "",
"addpay": "payload",
"append": "",
"useSpawn": "false",
"timer": "",
"winHide": false,
"oldrc": false,
"name": "cURL",
"x": 1090,
"y": 180,
"wires": [
[
"317d17a92e168a53",
"8f8bc645d83637d5"
],
[],
[]
]
},
{
"id": "7a090c427aadeb60",
"type": "function",
"z": "7057b52ef757d606",
"name": "Function: Create Pixel",
"func": "var glucose = msg.payload[0].sgv; // Data from Nightscout JSON\nvar delta = Math.round(msg.payload[0].delta);\nvar direction = msg.payload[0].direction;\nvar measuringtime = msg.payload[0].date;\nvar now = new Date();\nvar timestamp = now.getTime();\nvar nodataoffset = 660000; // Offset in milliseconds to the last measurement\nvar icon = \"\";\nvar color = \"\";\n\nif (delta >= 0) {\n delta = '+' + delta; // Insert plus sign for positive delta\n}\n\nif ((measuringtime + nodataoffset) < timestamp) {\n icon = 39552; // Set NoData icon if no data is available after the selected offset time\n} else { // Set icon depending on direction\n if (direction == \"SingleUp\") {\n icon = 39545;\n } else if (direction == \"SingleDown\") {\n icon = 39546;\n } else if (direction == \"Flat\") {\n icon = 39547;\n } else if (direction == \"FortyFiveDown\") {\n icon = 39548;\n } else if (direction == \"FortyFiveUp\") {\n icon = 39549;\n } else if (direction == \"DoubleUp\") {\n icon = 39550;\n } else if (direction == \"DoubleDown\") {\n icon = 39551;\n } \n}\n\n// Create payload to display on Awtrix depending on glucose level\nif (glucose > 250) {\n\n if ((measuringtime + nodataoffset) < timestamp) {\n color = [255, 255, 255];\n } else {\n color = [247, 133, 31];\n }\n\n msg.payload = {\n \"text\": glucose + ' ' + delta,\n \"icon\": icon,\n \"color\": color,\n \"pushIcon\": 0,\n \"save\": true,\n \"textCase\": 2\n };\n return [{ payload: msg.payload }, null];\n} else if (glucose < 70) {\n\n if ((measuringtime + nodataoffset) < timestamp) {\n color = [255, 255, 255];\n } else {\n color = [255, 0, 0];\n }\n\n msg.payload = {\n \"text\": glucose + ' ' + delta,\n \"icon\": icon,\n \"color\": color,\n \"pushIcon\": 0,\n \"save\": true,\n \"textCase\": 2\n };\n return [{ payload: msg.payload }, null];\n} else if (glucose => 70 && glucose <= 250) {\n\n if ((measuringtime + nodataoffset) < timestamp) {\n color = [255, 255, 255];\n } else {\n color = [0, 255, 0];\n }\n \n msg.payload = {\n \"text\": glucose + ' ' + delta,\n \"icon\": icon,\n \"color\": color,\n \"pushIcon\": 0,\n \"save\": true,\n \"textCase\": 2\n };\n return [{ payload: msg.payload }, null];\n}\n\nreturn msg;",
"outputs": 1,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 1420,
"y": 180,
"wires": [
[
"d3ef3ba51867a7aa"
]
]
},
{
"id": "317d17a92e168a53",
"type": "debug",
"z": "7057b52ef757d606",
"name": "Debug: Nightscout JSON",
"active": false,
"tosidebar": true,
"console": false,
"tostatus": false,
"complete": "payload",
"targetType": "msg",
"statusVal": "",
"statusType": "auto",
"x": 1290,
"y": 220,
"wires": []
},
{
"id": "1ac6b90937457bf7",
"type": "change",
"z": "7057b52ef757d606",
"name": "Command: Token request",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "curl -X GET https://NIGHTSCOUT_URL:PORT/api/v2/authorization/request/ACCESS_TOKEN -H \"Content-Type: application/json\"",
"tot": "str"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 270,
"y": 180,
"wires": [
[
"018aaebd60f06dff"
]
]
},
{
"id": "018aaebd60f06dff",
"type": "exec",
"z": "7057b52ef757d606",
"command": "",
"addpay": "payload",
"append": "",
"useSpawn": "false",
"timer": "",
"winHide": false,
"oldrc": false,
"name": "cURL",
"x": 450,
"y": 180,
"wires": [
[
"a3561344ac2dae6d"
],
[],
[]
]
},
{
"id": "a3561344ac2dae6d",
"type": "json",
"z": "7057b52ef757d606",
"name": "parsing",
"property": "payload",
"action": "",
"pretty": false,
"x": 580,
"y": 180,
"wires": [
[
"25b695a46aa59b69",
"360750b08aaad716"
]
]
},
{
"id": "360750b08aaad716",
"type": "change",
"z": "7057b52ef757d606",
"name": "save token",
"rules": [
{
"t": "set",
"p": "Nightscout.Token",
"pt": "flow",
"to": "payload.token",
"tot": "msg"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 730,
"y": 220,
"wires": [
[]
]
},
{
"id": "1e1f42891a8b5b97",
"type": "change",
"z": "7057b52ef757d606",
"name": "insert token",
"rules": [
{
"t": "change",
"p": "payload",
"pt": "msg",
"from": "TOKEN",
"fromt": "str",
"to": "Nightscout.Token",
"tot": "flow"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 950,
"y": 180,
"wires": [
[
"fd30a342bc5bed2f"
]
]
},
{
"id": "d3ef3ba51867a7aa",
"type": "mqtt out",
"z": "7057b52ef757d606",
"name": "Nightscout Custom App",
"topic": "PREFIX/custom/Nightscout",
"qos": "1",
"retain": "false",
"respTopic": "",
"contentType": "",
"userProps": "",
"correl": "",
"expiry": "",
"broker": "326ea0d44da2b88f",
"x": 1650,
"y": 180,
"wires": []
},
{
"id": "8f8bc645d83637d5",
"type": "json",
"z": "7057b52ef757d606",
"name": "parsing",
"property": "payload",
"action": "",
"pretty": false,
"x": 1240,
"y": 180,
"wires": [
[
"7a090c427aadeb60"
]
]
},
{
"id": "326ea0d44da2b88f",
"type": "mqtt-broker",
"name": "",
"broker": "",
"port": "1883",
"clientid": "",
"autoConnect": true,
"usetls": false,
"protocolVersion": "4",
"keepalive": "60",
"cleansession": true,
"birthTopic": "",
"birthQos": "0",
"birthPayload": "",
"birthMsg": {},
"closeTopic": "",
"closeQos": "0",
"closePayload": "",
"closeMsg": {},
"willTopic": "",
"willQos": "0",
"willPayload": "",
"willMsg": {},
"userProps": "",
"sessionExpiry": ""
}
]
These icons belong on the device, in /ICONS. Each one is at
most 32×8
pixels — shown here magnified, at their real proportions.
8×8 px
8×8 px
8×8 px
8×8 px
8×8 px
8×8 px
8×8 px
8×8 px
