This flow was submitted before accounts existed, so nobody owns it yet. If you submitted it, open the edit link you were given — it still works — and you can attach the flow to an account from there. There is no deadline, and attaching it retires the link for good.
This uses the FlightRadar24 integration with HomeAssistant: FlightRadar24 HACS Integration - credit to AlexandrErohin.
It will send a notification to your clock with the flight number, source location, and destination location. You can customize the function node to your liking.
Additionally, not only does this send out a notification to the clock, there is a second MQTT out which sets it as an app so you can review the last flight overhead :)
**BEFORE IMPLEMENTING: **review the code and fill out the necessary information:
My FlightRadar24 entities have the default naming nomenclature. Change yours if necessary.
[awtrixName] = MQTT name of your AWTRIX clock
[brokerName] = MQTT Broker Name (usually HomeAssistant-Int)
[brokerIP] = MQTT Broker IP address
[brokerPort] = MQTT port
npWxo0GjAvJk.json
[
{
"id": "8746a5bd8155578f",
"type": "group",
"z": "6190826355af2250",
"style": {
"stroke": "#232433",
"stroke-opacity": "1",
"fill": "#16161e",
"fill-opacity": "0.5",
"label": true,
"label-position": "nw",
"color": "#787c99"
},
"nodes": [
"7bb3435685b38890",
"41af1f322728d999",
"eb4c784ee52582e7",
"4ab4e14182e95811",
"c5e74ec0f702b77e"
],
"x": 1334,
"y": 399,
"w": 832,
"h": 122
},
{
"id": "7bb3435685b38890",
"type": "server-state-changed",
"z": "6190826355af2250",
"g": "8746a5bd8155578f",
"name": "Flight Overhead",
"server": "f0e55252.db692",
"version": 6,
"outputs": 2,
"exposeAsEntityConfig": "",
"entities": {
"entity": [
"sensor.flightradar24_current_in_area"
],
"substring": [],
"regex": []
},
"outputInitially": false,
"stateType": "num",
"ifState": "1",
"ifStateType": "num",
"ifStateOperator": "gte",
"outputOnlyOnStateChange": false,
"for": "0",
"forType": "num",
"forUnits": "minutes",
"ignorePrevStateNull": false,
"ignorePrevStateUnknown": false,
"ignorePrevStateUnavailable": false,
"ignoreCurrentStateUnknown": true,
"ignoreCurrentStateUnavailable": true,
"outputProperties": [
{
"property": "payload",
"propertyType": "msg",
"value": "number",
"valueType": "entityState"
},
{
"property": "data",
"propertyType": "msg",
"value": "",
"valueType": "eventData"
},
{
"property": "topic",
"propertyType": "msg",
"value": "",
"valueType": "triggerId"
}
],
"x": 1440,
"y": 440,
"wires": [
[
"eb4c784ee52582e7"
],
[]
]
},
{
"id": "41af1f322728d999",
"type": "function",
"z": "6190826355af2250",
"g": "8746a5bd8155578f",
"name": "Create Msg",
"func": "let flights = msg.data.new_state.attributes.flights[0];\n\nlet flight_number = flights.flight_number || \"N/A\";\nlet aircraft_registration = flights.aircraft_registration || \"N/A\";\nlet aircraft_model = flights.aircraft_model || \"N/A\";\nlet origin = flights.airport_origin_code_icao || \"UNK\";\nlet destination = flights.airport_destination_code_icao || \"UNK\";\nlet speed = flights.ground_speed || \"N/A\";\n\n// AWTRIX payload format\nmsg.payload = {\n \"name\": \"flights\",\n \"text\": `${flight_number} ${origin} > ${destination}`,\n \"icon\": \"31805\",\n \"duration\": \"15\",\n \"repeat\": \"3\",\n \"scrollspeed\": \"100\",\n \"pushicon\": \"2\",\n \"save\": true,\n \"stack\": false\n}\n;\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 1790,
"y": 440,
"wires": [
[
"4ab4e14182e95811",
"c5e74ec0f702b77e"
]
]
},
{
"id": "eb4c784ee52582e7",
"type": "delay",
"z": "6190826355af2250",
"g": "8746a5bd8155578f",
"name": "",
"pauseType": "rate",
"timeout": "5",
"timeoutUnits": "seconds",
"rate": "1",
"nbRateUnits": "1",
"rateUnits": "minute",
"randomFirst": "1",
"randomLast": "5",
"randomUnits": "seconds",
"drop": true,
"allowrate": false,
"outputs": 1,
"x": 1610,
"y": 440,
"wires": [
[
"41af1f322728d999"
]
]
},
{
"id": "4ab4e14182e95811",
"type": "mqtt out",
"z": "6190826355af2250",
"g": "8746a5bd8155578f",
"name": "",
"topic": "[awtrixName]/notify",
"qos": "",
"retain": "",
"respTopic": "",
"contentType": "",
"userProps": "",
"correl": "",
"expiry": "",
"broker": "eaca5628813067ea",
"x": 2010,
"y": 480,
"wires": []
},
{
"id": "c5e74ec0f702b77e",
"type": "mqtt out",
"z": "6190826355af2250",
"g": "8746a5bd8155578f",
"name": "",
"topic": "[awtrixName]/custom/flights",
"qos": "",
"retain": "",
"respTopic": "",
"contentType": "",
"userProps": "",
"correl": "",
"expiry": "",
"broker": "eaca5628813067ea",
"x": 2030,
"y": 440,
"wires": []
},
{
"id": "eaca5628813067ea",
"type": "mqtt-broker",
"name": "[brokerName]",
"broker": "[brokerIP]",
"port": "[brokerPort]",
"clientid": "",
"autoConnect": true,
"usetls": false,
"protocolVersion": "4",
"keepalive": "60",
"cleansession": true,
"autoUnsubscribe": true,
"birthTopic": "",
"birthQos": "0",
"birthRetain": "false",
"birthPayload": "",
"birthMsg": {},
"closeTopic": "",
"closeQos": "0",
"closeRetain": "false",
"closePayload": "",
"closeMsg": {},
"willTopic": "",
"willQos": "0",
"willRetain": "false",
"willPayload": "",
"willMsg": {},
"userProps": "",
"sessionExpiry": ""
},
{
"id": "fc8d200576f4ba3c",
"type": "global-config",
"env": [],
"modules": {
"node-red-contrib-home-assistant-websocket": "0.80.3"
}
}
]
