3D Print Status

blueprint:
  name: "AWTRIX 3D Print Status - Moonraker"
  description: "This blueprint will show the status of your 3d print, with help of the Moonraker HA intergration"
  source_url: https://github.com/RDG88/Homeassistant_Blueprints/blob/main/moonraker_awtrix_app.yaml
  domain: automation
  input:
    awtrix:
      name: AWTRIX Light
      description: Select the Awtrix light
      selector:
        device:
          integration: mqtt
          manufacturer: Blueforcer
          model: AWTRIX 3
          multiple: false
    awtrix_app_name:
      name: AWTRIX Application name
      description: This is the custom app name that will be added to AWTRIX, should be unique
      selector:
        text: {}
      default: 3d_print
    3dprint_progress_sensor:
      name: 3D Print Progress Sensor
      description: 3D Print progress sensor
      selector:
        entity:
          multiple: false
          filter:
            - integration: moonraker
    3dprint_current_state_sensor:
      name: 3D Print Current State Sensor
      description: 3D Print Current State sensor
      selector:
        entity:
          multiple: false
          filter:
            - integration: moonraker
    3dprint_icon:
      name: Icon
      description: Enter the Icon Name or ID of the icon that you like to show.
      selector:
        text:
      default: "51841"
    push_icon:
      name: Icon Mode
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: Icon doesn't move (default)
              value: "0"
            - label: Icon moves with text and will not appear again
              value: "1"
            - label:
                Icon moves with text but appears again when the text starts to
                scroll again
              value: "2"
          multiple: false
          custom_value: false
    txt_color_printing:
      name: Text Color Printing State
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    txt_color_error:
      name: Text Color Error State
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 0, 0]
    txt_color_paused:
      name: Text Color Paused State
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 0]
    txt_color_canceled:
      name: Text Color Canceled State
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 165, 0]
    txt_color_complete:
      name: Text Color Complete State
      description: Select the Text color
      selector:
        color_rgb:
      default: [66, 245, 75]
    stack_notification:
      name: Stack notification
      description: Should the notifications be stacked?
      selector:
        boolean:
      default: false
    duration:
      name: Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    repeat:
      name: Repeat
      description: Sets how many times the text should be scrolled through the matrix before the app/notifcation ends.
      default: "4"

variables:
  device_id: !input awtrix
  awtrix: "{{ iif( device_attr(device_id, 'name_by_user') != none, device_attr(device_id,'name_by_user'), device_attr(device_id, 'name') ) }}"
  app: !input awtrix_app_name
  message_topic: "{{awtrix ~ '/custom/' ~ app }}"
  icon: !input 3dprint_icon
  notify_topic: "{{awtrix ~ '/notify'}}"
  sensor_progress: !input 3dprint_progress_sensor
  sensor_current_state: !input 3dprint_current_state_sensor
  txt_color_printing: !input txt_color_printing
  txt_color_error: !input txt_color_error
  txt_color_paused: !input txt_color_paused
  txt_color_canceled: !input txt_color_canceled
  txt_color_complete: !input txt_color_complete
  stack_notification: !input stack_notification
  push_icon: !input push_icon
  duration: !input duration
  repeat: !input repeat

trigger:
  - platform: state
    entity_id:
      - !input 3dprint_progress_sensor
  - platform: state
    entity_id:
      - !input 3dprint_current_state_sensor
condition:
  - condition: not
    conditions:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: unavailable
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: unknown
action:
  - if:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: printing
    then:
      - service: mqtt.publish
        data:
          topic: "{{ message_topic }}"
          payload: |-
            {
              "text": "{{ states(sensor_progress) }}%",
              "icon": "{{ icon }}",
              "progress": "{{ states(sensor_progress) }}",
              "pushIcon": {{ push_icon }},
              "color": {{ txt_color_printing }},
              "duration": {{ duration }},
              "repeat": {{ repeat }}
            }
    else:
      - service: mqtt.publish
        data:
          topic: "{{ message_topic }}"
  - if:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: error
    then:
      - service: mqtt.publish
        data:
          topic: "{{ notify_topic }}"
          payload: |-
            {
              "text": "{{ states(sensor_current_state) }}",
              "icon": "{{ icon }}",
              "color": {{ txt_color_error }},
              "stack": {{ iif(stack_notification, "true", "false") }},
              "pushIcon": {{ push_icon }},
              "duration": {{ duration }},
              "repeat": {{ repeat }}
            }
  - if:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: cancelled
    then:
      - service: mqtt.publish
        data:
          topic: "{{ notify_topic }}"
          payload: |-
            {
              "text": "{{ states(sensor_current_state) }}",
              "icon": "{{ icon }}",
              "stack": {{ iif(stack_notification, "true", "false") }},
              "color": {{ txt_color_canceled }},
              "pushIcon": {{ push_icon }},
              "duration": {{ duration }},
              "repeat": {{ repeat }}
            }
  - if:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: paused
    then:
      - service: mqtt.publish
        data:
          topic: "{{ notify_topic }}"
          payload: |-
            {
              "text": "{{ states(sensor_current_state) }}",
              "icon": "{{ icon }}",
              "stack": {{ iif(stack_notification, "true", "false") }},
              "color": {{ txt_color_paused }},
              "pushIcon": {{ push_icon }},
              "duration": {{ duration }},
              "repeat": {{ repeat }}
            }

  - if:
      - condition: state
        entity_id: !input 3dprint_current_state_sensor
        state: complete
    then:
      - service: mqtt.publish
        data:
          topic: "{{ notify_topic }}"
          payload: |-
            {
              "text": "{{ states(sensor_current_state) }}",
              "icon": "{{ icon }}",
              "stack": {{ iif(stack_notification, "true", "false") }},
              "color": {{ txt_color_complete }},
              "pushIcon": {{ push_icon }},
              "duration": {{ duration }},
              "repeat": {{ repeat }}
            }
mode: restart

These icons belong on the device, in /ICONS. Each one is at most 32×8 pixels — shown here magnified, at their real proportions.
