Valentine’s Heart Animation

This script creates an animated heart sequence on the AWTRIX3 display, perfectly timed to bring Valentine’s Day cheer!

Specifications
System	Domoticz
Firmware	AWTRIX 3
Topic	Miscellaneous
Built by	Galadril
File	XjzBOy0woQl7.json · 4.7 KB
Icons	—
Published	7 Jan 2025 · updated 7 Jan 2025
Downloads	22

Download flow

❤️ AWTRIX3 Valentine’s Heart Animation Script ❤️

💡 Script Purpose:
This script creates an animated heart sequence on the AWTRIX3 display, perfectly timed to bring Valentine’s Day cheer!

⚙️ Script Activation:
The script is always active by default, as indicated by active = true.

🎛️ Trigger:
The animation is triggered by a device called 'SwithValentine', ensuring the heart animation starts only when manually activated.

📝 Logging:
Custom logging is used with a marker "AWTRIX_HEART" for easy identification of Valentine-specific log entries.

🔍 Conditions:

The device "AWTRIX3 - Power" is checked to ensure the AWTRIX3 display is powered on:
🛑 If "AWTRIX3 - Power" is not found or is Off, the script halts execution.
The device "AWTRIX3 - Send Custom App" is verified:
🛑 If this device is not found, an error is logged, and the script stops further actions.

🚀 Execution Flow:
Once the conditions are met:

A sequence of five animated heart frames is prepared as JSON payloads.
Each frame contains a precise arrangement of pixel data ("dp") with colors (e.g., "#971B23" for deep red and "#FFFF00" for yellow accents).
These frames are explicitly sent to the AWTRIX3 device (AWTRIX3 - Send Custom App) with timed intervals using .afterSec() for smooth animation.

🎥 Animation Details:

The heart evolves frame by frame, starting as a small core and expanding into a detailed, glowing heart with outer yellow highlights.
The animation loops seamlessly with a dynamic flow and vibrant red hues, creating an engaging visual display.

✅ Final Touch:
A log entry "Animation scheduling completed." confirms the animation setup is successfully scheduled.

🌹 Valentine’s Special:
This creative script ensures your AWTRIX3 display spreads love and warmth, making it a delightful centerpiece for Valentine’s Day celebrations!

🔗 More Information:

XjzBOy0woQl7.json

return {
    active = true,

    on = {
        devices = {
            'SwithValentine'
        }
    },

    logging = {
        level = domoticz.LOG_INFO,
        marker = "AWTRIX_HEART"
    },

    execute = function(domoticz)

        local appDevice = domoticz.devices('AWTRIX3 - Send Custom App')
        if not appDevice then
            domoticz.log("AWTRIX3 - Send Custom App device not found", domoticz.LOG_ERROR)
            return
        end

        -- JSON payloads for the animation steps (as strings)
        local animationFrames = {
            -- Start of Heart (as a JSON string)
            '{"draw":[{"dp":[14,3,"#971B23"]},{"dp":[15,3,"#971B23"]},{"dp":[13,4,"#971B23"]},{"dp":[16,4,"#971B23"]},{"dp":[12,5,"#971B23"]},{"dp":[17,5,"#971B23"]},{"dp":[13,6,"#971B23"]},{"dp":[16,6,"#971B23"]},{"dp":[14,7,"#971B23"]},{"dp":[15,7,"#971B23"]}]}',
            '{"draw":[{"dp":[13,2,"#971B23"]},{"dp":[14,2,"#971B23"]},{"dp":[15,2,"#971B23"]},{"dp":[16,2,"#971B23"]},{"dp":[12,3,"#971B23"]},{"dp":[17,3,"#971B23"]},{"dp":[11,4,"#971B23"]},{"dp":[18,4,"#971B23"]},{"dp":[12,5,"#971B23"]},{"dp":[17,5,"#971B23"]},{"dp":[13,6,"#971B23"]},{"dp":[16,6,"#971B23"]},{"dp":[14,7,"#971B23"]},{"dp":[15,7,"#971B23"]}]}',
            '{"draw":[{"dp":[12,1,"#971B23"]},{"dp":[13,1,"#971B23"]},{"dp":[16,1,"#971B23"]},{"dp":[17,1,"#971B23"]},{"dp":[11,2,"#971B23"]},{"dp":[14,2,"#971B23"]},{"dp":[15,2,"#971B23"]},{"dp":[18,2,"#971B23"]},{"dp":[10,3,"#971B23"]},{"dp":[19,3,"#971B23"]},{"dp":[11,4,"#971B23"]},{"dp":[18,4,"#971B23"]},{"dp":[12,5,"#971B23"]},{"dp":[17,5,"#971B23"]},{"dp":[13,6,"#971B23"]},{"dp":[16,6,"#971B23"]},{"dp":[14,7,"#971B23"]},{"dp":[15,7,"#971B23"]}]}',
            '{"draw":[{"dp":[12,1,"#971B23"]},{"dp":[13,1,"#971B23"]},{"dp":[16,1,"#971B23"]},{"dp":[17,1,"#971B23"]},{"dp":[11,2,"#971B23"]},{"dp":[12,2,"#FFFFFF"]},{"dp":[13,2,"#FFFFFF"]},{"dp":[14,2,"#971B23"]},{"dp":[15,2,"#971B23"]},{"dp":[16,2,"#FF0000"]},{"dp":[17,2,"#FF0000"]},{"dp":[18,2,"#971B23"]},{"dp":[10,3,"#971B23"]},{"dp":[11,3,"#FF0000"]},{"dp":[12,3,"#FFFFFF"]},{"dp":[13,3,"#FF0000"]},{"dp":[14,3,"#FF0000"]},{"dp":[15,3,"#FF0000"]},{"dp":[16,3,"#FF0000"]},{"dp":[17,3,"#FF0000"]},{"dp":[18,3,"#D01B23"]},{"dp":[19,3,"#971B23"]},{"dp":[11,4,"#971B23"]},{"dp":[12,4,"#FF0000"]},{"dp":[13,4,"#FF0000"]},{"dp":[14,4,"#FF0000"]},{"dp":[15,4,"#FF0000"]},{"dp":[16,4,"#FF0000"]},{"dp":[17,4,"#D01B23"]},{"dp":[18,4,"#971B23"]},{"dp":[12,5,"#971B23"]},{"dp":[13,5,"#FF0000"]},{"dp":[14,5,"#FF0000"]},{"dp":[15,5,"#FF0000"]},{"dp":[16,5,"#D01B23"]},{"dp":[17,5,"#971B23"]},{"dp":[13,6,"#971B23"]},{"dp":[14,6,"#FF0000"]},{"dp":[15,6,"#D01B23"]},{"dp":[16,6,"#971B23"]},{"dp":[14,7,"#971B23"]},{"dp":[15,7,"#971B23"]}]}',
            '{"draw":[{"dp":[12,1,"#971B23"]},{"dp":[13,1,"#971B23"]},{"dp":[16,1,"#971B23"]},{"dp":[17,1,"#971B23"]},{"dp":[11,2,"#971B23"]},{"dp":[12,2,"#FFFFFF"]},{"dp":[13,2,"#FFFFFF"]},{"dp":[14,2,"#971B23"]},{"dp":[15,2,"#971B23"]},{"dp":[16,2,"#FF0000"]},{"dp":[17,2,"#FF0000"]},{"dp":[18,2,"#971B23"]},{"dp":[10,3,"#971B23"]},{"dp":[11,3,"#FF0000"]},{"dp":[12,3,"#FFFFFF"]},{"dp":[13,3,"#FF0000"]},{"dp":[14,3,"#FF0000"]},{"dp":[15,3,"#FF0000"]},{"dp":[16,3,"#FF0000"]},{"dp":[17,3,"#FF0000"]},{"dp":[18,3,"#D01B23"]},{"dp":[19,3,"#971B23"]},{"dp":[11,4,"#971B23"]},{"dp":[12,4,"#FF0000"]},{"dp":[13,4,"#FF0000"]},{"dp":[14,4,"#FF0000"]},{"dp":[15,4,"#FF0000"]},{"dp":[16,4,"#FF0000"]},{"dp":[17,4,"#D01B23"]},{"dp":[18,4,"#971B23"]},{"dp":[12,5,"#971B23"]},{"dp":[13,5,"#FF0000"]},{"dp":[14,5,"#FF0000"]},{"dp":[15,5,"#FF0000"]},{"dp":[16,5,"#D01B23"]},{"dp":[17,5,"#971B23"]},{"dp":[13,6,"#971B23"]},{"dp":[14,6,"#FF0000"]},{"dp":[15,6,"#D01B23"]},{"dp":[16,6,"#971B23"]},{"dp":[14,7,"#971B23"]},{"dp":[15,7,"#971B23"]},{"dp":[12,0,"#FFFF00"]},{"dp":[17,0,"#FFFF00"]},{"dp":[10,1,"#FFFF00"]},{"dp":[19,1,"#FFFF00"]},{"dp":[9,3,"#FFFF00"]},{"dp":[20,3,"#FFFF00"]},{"dp":[10,5,"#FFFF00"]},{"dp":[19,5,"#FFFF00"]},{"dp":[12,8,"#FFFF00"]},{"dp":[17,8,"#FFFF00"]}]}'
        }

        domoticz.log("AWTRIX3 turned on, starting heart animation.", domoticz.LOG_INFO)

        -- Explicitly schedule each frame update
        appDevice.setDescription(animationFrames[1]).afterSec(0.5)
        appDevice.switchOn().afterSec(1)

        appDevice.setDescription(animationFrames[2]).afterSec(1.5)
        appDevice.switchOn().afterSec(2)

        appDevice.setDescription(animationFrames[3]).afterSec(2.5)
        appDevice.switchOn().afterSec(3)

        appDevice.setDescription(animationFrames[4]).afterSec(3.5)
        appDevice.switchOn().afterSec(4)

        appDevice.setDescription(animationFrames[5]).afterSec(4)
        appDevice.switchOn().afterSec(4.5)

        domoticz.log("Animation scheduling completed.", domoticz.LOG_INFO)
    end
}
