blueprint:
  name: Bambulab AWTRIX 3 Printer Assistant
  description: >
    # Bambulab AWTRIX 3 Printer Assistant

    is an advanced Home Assistant automation blueprint, specifically designed for Bambu Lab printers. It provides a seamless integration into your smart home system, enabling enhanced monitoring of your 3D printing tasks.

    ## Features:

    - AWTRIX 3 Control: Utilizes MQTT for real-time print status updates and visual alerts on your AWTRIX Light.

    - Comprehensive Print Monitoring: Tracks nozzle temperature, remaining print time, bed temperature, layer progress, and task names.

    - Customizable Notifications: Offers configurable options for notification icons, text colors, and durations, adapting to various print stages like bed leveling and nozzle heating.

    - Progress Bar Display: Optional visual representation of print progress on AWTRIX Light.

    - MQTT Protocol: Ensures efficient communication between your printer and Home Assistant setup.

    - Detailed Customization: Includes settings for text format, icon behavior, and RGB color choices for notifications.

    The blueprint is created with help of the bambulab HACS integration, and therefore is required.
    It is designed with help of the P1S, but should work with any Bambulab printer and the HACS integration.

  domain: automation
  input:
    awtrix:
      name: AWTRIX 3
      description: Select the Awtrix 3 device
      selector:
        device:
          filter:
            - integration: mqtt
              manufacturer: Blueforcer
              model: AWTRIX 3
          multiple: true
    appname:
      name: Awtrix Application name
      description: This is the app name listed in the MQTT topic - it should be unique
      default: "print_status"
      selector:
        text:
    print_status_select:
      name: Print status - Select the print status
      description:
        "Enables selection of multiple print status metrics for monitoring.\n\n
        nozzle_temp: Tracks nozzle temperature.\n
        remaining_time: Monitors remaining print duration.\n
        bed_temp: Observes bed temperature.\n
        layers: Follows layer-by-layer progress.\n
        task_name: Displays current task name.\n"
      selector:
        select:
          options:
            - label: Nozzle
              value: nozzle_temp
            - label: Remaining Time
              value: remaining_time
            - label: Bed Temperature
              value: bed_temp
            - label: Layers
              value: layers
            - label: Task Name
              value: task_name
          multiple: true
      default:
        ["nozzle_temp", "remaining_time", "bed_temp", "layers", "task_name"]
    print_status_show_progress:
      name: Print status - Show progress bar in AWTRIX
      description: Show progress bar in AWTRIX
      selector:
        boolean:
      default: true
    print_status_nozzle_temp_push_icon:
      name: Print status - Nozzle Temperature - Push Icon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    print_status_nozzle_temp_text_color:
      name: Print status - Nozzle Temperature - Text Color
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    print_status_nozzle_temp_duration:
      name: Print status - Nozzle Temperature - Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    print_status_nozzle_temp_icon:
      name: Print status - Nozzle Temperature - Icon
      description: "Enter the Icon Name that you like to show (this file should exist on the AWTRIX device).\nDo not add the file extension"
      default: "bl_heatnozzle"
    print_status_nozzle_temp_format:
      name: Nozzle Temperature Format
      description: "Define the format for displaying nozzle temperatures. Use %nozzle_current_temp% for current temperature and %nozzle_target_temp% for target temperature."
      default: "%nozzle_current_temp% / %nozzle_target_temp%"
      selector:
        text:
    print_status_task_name_push_icon:
      name: print_status_task_name_pushIcon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    print_status_task_name_text_color:
      name: Text Color for task_name
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    print_status_task_name_duration:
      name: print_status_task_name_duration Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    print_status_task_name_icon:
      name: Print Status Task Name Icon
      description: Print Status Task Name Icon
      default: "bl_green"
    print_status_task_name_format:
      name: Nozzle Temperature Format
      description: "Define the format for displaying task name. Use %task_name% for current task name"
      default: "Task: %task_name%"
      selector:
        text:
    print_status_layer_push_icon:
      name: print_status_layer_pushIcon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    print_status_layer_text_color:
      name: Text Color for layer
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    print_status_layer_duration:
      name: print_status_layer_duration Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    print_status_layer_icon:
      name: Layer icon
      description: Layer icon
      default: "bl_green"
    print_status_layer_format:
      name: Layer Format
      description: "Define the format for displaying layer. Use %current_layer% / %total_layers%"
      default: "%current_layer% / %total_layers%"
      selector:
        text:
    print_status_bed_temp_push_icon:
      name: print_status_bed_temp_pushIcon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    print_status_bed_temp_text_color:
      name: Text Color for bed_temp
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    print_status_bed_temp_duration:
      name: print_status_bed_temp_duration Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    print_status_bed_temp_icon:
      name: bed_temp icon
      description: bed_temp icon
      default: "bl_heatbed"
    print_status_bed_temp_format:
      name: bed_temp Format
      description: "Define the format for displaying bed_temp. Use %current_bed_temp% / %target_bed_temp%"
      default: "%current_bed_temp% / %target_bed_temp%"
      selector:
        text:
    print_status_remaining_time_push_icon:
      name: print_status_remaining_time_pushIcon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    print_status_remaining_time_text_color:
      name: Text Color for remaining_time
      description: Select the Text color
      selector:
        color_rgb:
      default: [255, 255, 255]
    print_status_remaining_time_duration:
      name: print_status_remaining_time_duration Duration (in seconds)
      description: Sets how long the app or notification should be displayed.
      default: "10"
    print_status_remaining_time_icon:
      name: remaining_time icon
      description: remaining_time icon
      default: "bl_time_green"
    print_status_remaining_time_format:
      name: remaining_time Format
      description: "Define the format for displaying remaining_time. Use %remaining_time% "
      default: "-%remaining_time% m"
      selector:
        text:
    stage_status_select:
      name: Stage status - Select the stage status
      description: Select the stage status
      selector:
        select:
          options:
            - label: Auto bed leveling
              value: auto_bed_leveling
            - label: Heatbed Preheating
              value: heatbed_preheating
            - label: Heating Hotend
              value: heating_hotend
            - label: Cleaning Nozzle Tip
              value: cleaning_nozzle_tip
          multiple: true
      default:
        [
          "auto_bed_leveling",
          "heatbed_preheating",
          "heating_hotend",
          "cleaning_nozzle_tip",
        ]
    stage_status_abl_text_color:
      name: Text Color for nozzle stage_status_abl_text_color
      description: Select the Text stage_status_abl_text_color
      selector:
        color_rgb:
      default: [55, 158, 47]
    stage_status_abl_icon:
      name: stage_status_abl_text_icon
      description: stage_status_abl_text_icon
      default: "bl_bedlevel"
    stage_status_abl_format:
      name: Nozzle Temperature Format
      description: "Define the format for displaying ABL"
      default: "Auto bed leveling"
      selector:
        text:
    stage_status_abl_push_icon:
      name: print_status_nozzle_temp_pushIcon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    stage_status_heatbed_text_color:
      name: Text Color for heatbed
      description: Select the Text heatbed
      selector:
        color_rgb:
      default: [55, 158, 47]
    stage_status_heatbed_icon:
      name: stage_status_heatbed_icon
      description: stage_status_heatbed_icon
      default: "bl_heatbed"
    stage_status_heatbed_format:
      name: stage_status_heatbed_format
      description: "Define the format for stage_status_heatbed_format"
      default: "Heatbed Preheating"
      selector:
        text:
    stage_status_heatbed_push_icon:
      name: stage_status_heatbed_push_icon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    stage_status_heatnozzle_text_color:
      name: Text Color for heatnozzle
      description: Select the Text heatnozzle
      selector:
        color_rgb:
      default: [55, 158, 47]
    stage_status_heatnozzle_icon:
      name: stage_status_heatnozzle_icon
      description: stage_status_heatnozzle_icon
      default: "bl_heatnozzle"
    stage_status_heatnozzle_format:
      name: stage_status_heatnozzle_format
      description: "Define the format for stage_status_heatnozzle_format"
      default: "Nozzle Preheating"
      selector:
        text:
    stage_status_heatnozzle_push_icon:
      name: stage_status_heatnozzle_push_icon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    stage_status_cleannozzle_text_color:
      name: Text Color for cleannozzle
      description: Select the Text cleannozzle
      selector:
        color_rgb:
      default: [55, 158, 47]
    stage_status_cleannozzle_icon:
      name: stage_status_cleannozzle_icon
      description: stage_status_cleannozzle_icon
      default: "bl_cleannozzle"
    stage_status_cleannozzle_format:
      name: stage_status_cleannozzle_format
      description: "Define the format for stage_status_cleannozzle_format"
      default: "Cleaning Nozzle"
      selector:
        text:
    stage_status_cleannozzle_push_icon:
      name: stage_status_cleannozzle_push_icon
      description:
        "Please select the pushIcon setting for the icon\n\n  - `0`  Icon
        doesn't move\n\n  - `1`  Icon moves with text and will not appear again\n\n
        \ - `2` Icon moves with text but appears again when the text starts to scroll
        again\n"
      selector:
        select:
          options:
            - label: "Icon doesn't move."
              value: "0"
            - label: "Icon moves with text and will not reappear."
              value: "1"
            - label: "Icon moves with text but appears again when the text starts."
              value: "2"
          mode: list
      default: "0"
    sensor_bed_temperature:
      name: bed_temperature sensor
      description: Select your bed tempreature sensor
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
            - device_class: sensor
    sensor_target_bed_temperature:
      name: target_bed_temperature
      description: Select your bed target_bed_temperature
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
            - device_class: sensor
    sensor_nozzle_temperature:
      name: nozzle_temperature
      description: Select your nozzle_temperature
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
            - device_class: sensor
    sensor_nozzle_target_temperature:
      name: nozzle_target_temperature
      description: Select your nozzle_target_temperature
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
            - device_class: sensor
    sensor_print_progress:
      name: print_progress
      description: Select your print_progress
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_remaining_time:
      name: remaining_time
      description: Select your remaining_time
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_current_layer:
      name: current_layer
      description: Select your current_layer
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_total_layer_count:
      name: total_layer_count
      description: Select your total_layer_count
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_task_name:
      name: task_name
      description: Select your task_name
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_print_status:
      name: print_status
      description: Select your print_status
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab
    sensor_current_stage:
      name: current_stage
      description: Select your current_stage
      selector:
        entity:
          multiple: false
          filter:
            - integration: bambu_lab

variables:
  device_ids: !input awtrix
  devices: >-
    {% macro get_device(device_id) %}
      {{ states((device_entities(device_id) | select('search','device_topic') | list)[0] | default('unknown')) }}
    {% endmacro %}
    {% set ns = namespace(devices=[]) %}
    {% for device_id in device_ids %}
      {% set device=get_device(device_id)|replace(' ','')|replace('\n','') %}
      {% set ns.devices = ns.devices + [ device ] %}
    {% endfor %}
    {{ ns.devices | reject('match','unavailable|unknown') | list }}
  appname: !input appname
  val_sensor_bed_temperature: !input sensor_bed_temperature
  val_sensor_target_bed_temperature: !input sensor_target_bed_temperature
  val_sensor_nozzle_temperature: !input sensor_nozzle_temperature
  val_sensor_nozzle_target_temperature: !input sensor_nozzle_target_temperature
  val_sensor_print_progress: !input sensor_print_progress
  val_sensor_remaining_time: !input sensor_remaining_time
  val_sensor_current_layer: !input sensor_current_layer
  val_sensor_total_layer_count: !input sensor_total_layer_count
  val_sensor_task_name: !input sensor_task_name
  val_sensor_print_status: !input sensor_print_status
  val_sensor_current_stage: !input sensor_current_stage
  print_status_select: !input print_status_select
  print_status_show_progress: !input print_status_show_progress
  stage_status_select: !input stage_status_select
  stage_status_abl_text_color: !input stage_status_abl_text_color
  stage_status_abl_icon: !input stage_status_abl_icon
  stage_status_abl_format: !input stage_status_abl_format
  stage_status_abl_push_icon: !input stage_status_abl_push_icon
  stage_status_heatbed_text_color: !input stage_status_heatbed_text_color
  stage_status_heatbed_icon: !input stage_status_heatbed_icon
  stage_status_heatbed_format: !input stage_status_heatbed_format
  stage_status_heatbed_push_icon: !input stage_status_heatbed_push_icon
  stage_status_heatnozzle_text_color: !input stage_status_heatnozzle_text_color
  stage_status_heatnozzle_icon: !input stage_status_heatnozzle_icon
  stage_status_heatnozzle_format: !input stage_status_heatnozzle_format
  stage_status_heatnozzle_push_icon: !input stage_status_heatnozzle_push_icon
  stage_status_cleannozzle_text_color: !input stage_status_cleannozzle_text_color
  stage_status_cleannozzle_icon: !input stage_status_cleannozzle_icon
  stage_status_cleannozzle_format: !input stage_status_cleannozzle_format
  stage_status_cleannozzle_push_icon: !input stage_status_cleannozzle_push_icon
  print_status_nozzle_temp_format: !input print_status_nozzle_temp_format
  print_status_nozzle_temp_icon: !input print_status_nozzle_temp_icon
  print_status_nozzle_temp_duration: !input print_status_nozzle_temp_duration
  print_status_nozzle_temp_text_color: !input print_status_nozzle_temp_text_color
  print_status_task_name_format: !input print_status_task_name_format
  print_status_task_name_icon: !input print_status_task_name_icon
  print_status_task_name_duration: !input print_status_task_name_duration
  print_status_task_name_text_color: !input print_status_task_name_text_color
  print_status_layer_format: !input print_status_layer_format
  print_status_layer_icon: !input print_status_layer_icon
  print_status_layer_duration: !input print_status_layer_duration
  print_status_layer_text_color: !input print_status_layer_text_color
  print_status_bed_temp_format: !input print_status_bed_temp_format
  print_status_bed_temp_icon: !input print_status_bed_temp_icon
  print_status_bed_temp_duration: !input print_status_bed_temp_duration
  print_status_bed_temp_text_color: !input print_status_bed_temp_text_color
  print_status_remaining_time_format: !input print_status_remaining_time_format
  print_status_remaining_time_icon: !input print_status_remaining_time_icon
  print_status_remaining_time_duration: !input print_status_remaining_time_duration
  print_status_remaining_time_text_color: !input print_status_remaining_time_text_color
  payload_stage: >-
    {% macro gen_stage_payload(icon, pushIcon, text, color) %}
      {
        "hold": true,
        "stack": false,
        "pushIcon": {{ pushIcon }},
        "icon": "{{ icon }}",
        "color": {{ color }},
        "text": "{{ text }}"
      }
    {% endmacro %}
    {% set printer_stage = states(val_sensor_current_stage) %}
    {% set all_stage_mappings = {
        "auto_bed_leveling": gen_stage_payload(stage_status_abl_icon, stage_status_abl_push_icon, stage_status_abl_format, stage_status_abl_text_color),
        "heatbed_preheating": gen_stage_payload(stage_status_heatbed_icon, stage_status_heatbed_push_icon, stage_status_heatbed_format, stage_status_heatbed_text_color),
        "heating_hotend": gen_stage_payload(stage_status_heatnozzle_icon, stage_status_heatnozzle_push_icon, stage_status_heatnozzle_format, stage_status_heatnozzle_text_color),
        "cleaning_nozzle_tip": gen_stage_payload(stage_status_cleannozzle_icon, stage_status_cleannozzle_push_icon, stage_status_cleannozzle_format, stage_status_cleannozzle_text_color),
    } %}
    {% set selected_stages = stage_status_select %}
    {% if printer_stage in selected_stages %}
      {{ all_stage_mappings.get(printer_stage, '') }}
    {% else %}
      ""
    {% endif %}
  payload_print_status: >-
    {% set show_progress = print_status_show_progress %}
    {% set enabled_items = print_status_select %}
    {# Function to create a payload item #}
    {% macro create_payload_item(name, icon, duration, text, color) -%}
        {"name": "{{ name }}", "icon": "{{ icon }}", "duration": {{ duration }}, "text": "{{ text }}", "color": {{ color }}}
    {%- endmacro -%}
    {# Function to generate the payload #}
    {% macro generate_payload(show_progress, progress, payload_items, enabled_items) %}
        [
            {%- for item in payload_items if item.name in enabled_items %}
                {{- create_payload_item(item.name, item.icon, item.duration, item.text, item.color) -}}
                {%- if not loop.last %},{% endif %}
            {%- endfor %}
            {%- if show_progress and progress is number -%}
                {%- if payload_items|length > 0 -%},{%- endif -%}
                "progress": {{ progress }}
            {%- endif -%}
        ]
    {%- endmacro -%}
    {# Formatting nozzle_temp_format strings #}
    {% set nozzle_temp_format = print_status_nozzle_temp_format
        | replace('%nozzle_current_temp%', states(val_sensor_nozzle_temperature))
        | replace('%nozzle_target_temp%', states(val_sensor_nozzle_target_temperature)) %}
    {# Formatting task_name_format strings #}
    {% set task_name_format = print_status_task_name_format
        | replace('%task_name%', states(val_sensor_task_name)) %}
    {# Formatting layer_format strings #}
    {% set layer_format = print_status_layer_format
        | replace('%current_layer%', states(val_sensor_current_layer))
        | replace('%total_layers%', states(val_sensor_total_layer_count)) %}
    {# Formatting bed_temp_format strings #}
    {% set bed_temp_format = print_status_bed_temp_format
        | replace('%current_bed_temp%', states(val_sensor_bed_temperature))
        | replace('%target_bed_temp%', states(val_sensor_target_bed_temperature)) %}
    {# Formatting remaining_time_format strings #}
    {% set remaining_time_format = print_status_remaining_time_format
        | replace('%remaining_time%', states(val_sensor_remaining_time)) %}
    {# Defining payload items - using the create_payload_item function #}
    {% set payload_items = [
        {"name": "remaining_time", "icon": print_status_remaining_time_icon, "duration": print_status_remaining_time_duration, "text": remaining_time_format, "color": print_status_remaining_time_text_color},
        {"name": "bed_temp", "icon": print_status_bed_temp_icon, "duration": print_status_bed_temp_duration, "text": bed_temp_format, "color": print_status_bed_temp_text_color},
        {"name": "layers", "icon": print_status_layer_icon, "duration": print_status_layer_duration, "text": layer_format, "color": print_status_layer_text_color},
        {"name": "task_name", "icon": print_status_task_name_icon, "duration": print_status_task_name_duration, "text": task_name_format, "color": print_status_task_name_text_color},
        {"name": "nozzle_temp", "icon": print_status_nozzle_temp_icon, "duration": print_status_nozzle_temp_duration, "text": nozzle_temp_format, "color": print_status_nozzle_temp_text_color}
    ] %}
    {{ generate_payload(show_progress, states(val_sensor_print_progress), payload_items, enabled_items) }}
  payload_finished: >-
    {
      "icon": "bl_green",
      "hold": false,
      "duration": 240,
      "stack": false,
      "text": "Done",
      "color": [0, 128, 0]
    }
  payload_failed: >-
    {
      "icon": "bl_red",
      "hold": false,
      "duration": 240,
      "stack": false,
      "text": "Failed",
      "color": [255, 0, 0]
    }
trigger:
  - platform: state
    entity_id: !input sensor_current_stage
    id: id_current_stage
  - platform: state
    entity_id: !input sensor_print_progress
    id: id_print_progress
  - platform: state
    entity_id: !input sensor_print_status
    id: id_printer_status_change
action:
  - repeat:
      for_each: "{{ devices }}"
      sequence:
        - choose:
            - conditions:
                - condition: and
                  conditions:
                    - condition: trigger
                      id:
                        - id_current_stage
                    - condition: template
                      value_template: "{{ states(val_sensor_current_stage) in stage_status_select }}"
              sequence:
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify/dismiss"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify"
                    payload: "{{ payload_stage }}"
            - conditions:
                - condition: and
                  conditions:
                    - condition: trigger
                      id:
                        - id_print_progress
                    - condition: numeric_state
                      entity_id: !input sensor_current_layer
                      above: "0"
                    - condition: numeric_state
                      entity_id: !input sensor_print_progress
                      above: "0"
                      below: 100
              sequence:
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify/dismiss"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/custom/{{ appname }}"
                    payload: "{{ payload_print_status }}"
            - conditions:
                - condition: template
                  value_template: >
                    {{ trigger.id == 'id_printer_status_change' and
                        trigger.from_state.state == 'running' and
                        trigger.to_state.state == 'finish'
                    }}
              sequence:
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify/dismiss"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/custom/{{ appname }}"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify"
                    payload: "{{ payload_finished }}"
            - conditions:
                - condition: template
                  value_template: >
                    {{ trigger.id == 'id_printer_status_change' and
                        trigger.from_state.state == 'running' and
                        trigger.to_state.state == 'failed'
                    }}
              sequence:
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify/dismiss"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/custom/{{ appname }}"
                - service: mqtt.publish
                  data:
                    topic: "{{ repeat.item }}/notify"
                    payload: "{{ payload_failed }}"
mode: restart

These icons belong on the device, in /ICONS. Each one is at most 32×8 pixels — shown here magnified, at their real proportions.
